HF 115X3 MM
Function description 1. Contactless passive label, conforming to ISO/IEC 18000-6C and EPC C1/G2 standards. 2. The storage capacity is 64 bytes, which can be used repeatedly. 3. The frequency error is less than or equal to ± 300K Hz. 4. Multi label anti-collision technology can ensure that multiple (more than 100) labels can be identified reliably at the same time, greatly improving the processing speed of data circulation. 5. With high security, data blocks can be locked to prevent data information from being overwritten at will. 6. AFI or EAS bits are used as security signs to judge whether circulation materials are allowed to be taken out of the library. 7. The label has its own single-sided or double-sided adhesive, which will not damage the surface of books and other media. It is not easy to tear off after pasting, and will not peel off during the warranty period Parameter Description ◆Size: 95 / 115 L X 3 W X 0.25 mm ◆Standards: ISO/IEC 18000-6C, EPC-C0, C1, C2, G2 ◆Chip model: Alien H3 ◆Label memory capacity:≥512bits ◆Packaging material: paper; PVC; PET；double faced adhesive tape ◆Substrate material: PET ◆Antenna thickness: 0.01mm ◆Reading distance: 0m~10m (antenna size, card reader power related) ◆Writing distance: 0m~8m (antenna size, power of card reader are related) ◆Conflict prevention: allow reliable reading of multiple labels in the working range ◆Data storage:≥10 years ◆Data rewriting:≥100000 times ◆Operating frequency: 902～928MHz ◆Data communication rate: 640K bits/s {HSL: 40K bits/s} ◆Withstand voltage:≤5N/m㎡ ◆Bending resistance:≥ φ20mm ◆Ambient temperature range: - 30℃~70℃
